Model | HY-2070 |
Effective Pixels | SONY 26MP SONY IMX sensor |
Pixel Size | 2.9 × 2.9μm |
Sensor Size | 1/2.8” |
Output Interface | HDMI/USB Standard USB2.0 interface (Type B) |
Resolution | 1920x1080@60FPS（HDMI） 1920x1080@30FPS(USB) |
Screen Size | 7.1 inch 1024x600 |
Resolution output | 16:9，4:3 |
Image Resolution | 4608 x 2592 |
Frame rate | 60@FPS |
Color | R/G/B |
Transverse and vertical line | Support multi-color, 5 pcs of transverse lines/vertical lines, movable |
Image Scaling | 8-Fold zoom |
Magnification | 50X-1200X |
Focus Range | 5cm to 35cm |
Lens Fype | C / CS |
Lens focus range | 5cm ~ ∞ cm |
PC Support | Support Windows / Mac / Linux System; PC Software with Measuring Functio |
Video /Image format | MP4 / JPEG |
Language | EN /FR /ES /Portugues /Deutsch /Italiano /CN/Pyccknn/ JP/DE |
Input Voltage | 12V/1500mA |
WaveLength | 400nm~1000nm |
HDR | Support |
Storage TF Card | 128GB |
Size | 170x120x200mm |
working temperature | -40°C~65°C |
